I have an ASUS ROG STRIX B650-A board and unfortunately no matter what I do, the analog audio cannot be detected.Things I have tried to do
❯ aplay -l
**** List of PLAYBACK Hardware Devices ****
card 0: HDMI [HDA ATI HDMI], device 3: HDMI 0 [HDMI 0]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 0: HDMI [HDA ATI HDMI], device 7: HDMI 1 [Odyssey G5]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 0: HDMI [HDA ATI HDMI], device 8: HDMI 2 [HDMI 2]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 0: HDMI [HDA ATI HDMI], device 9: HDMI 3 [HDMI 3]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 1: Generic [HD-Audio Generic], device 3: HDMI 0 [HDMI 0]
Subdevices: 0/1
Subdevice #0: subdevice #0
card 1: Generic [HD-Audio Generic], device 7: HDMI 1 [HDMI 1]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 2: Satellite [Samson Satellite], device 0: USB Audio [USB Audio]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 3: Audio [USB Audio], device 0: USB Audio [USB Audio]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 3: Audio [USB Audio], device 1: USB Audio [USB Audio #1]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 3: Audio [USB Audio], device 2: USB Audio [USB Audio #2]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 3: Audio [USB Audio], device 3: USB Audio [USB Audio #3]
Subdevices: 1/1
Subdevice #0: subdevice #0
Things I have tried:
unmuting following these steps:
$ amixer sset Master unmute $ amixer sset Speaker unmute $ amixer sset Headphone unmute
Only the master command works:
❯ amixer sset Master unmute
Simple mixer control ‘Master’,0
Capabilities: pvolume pswitch pswitch-joined
Playback channels: Front Left - Front Right - Rear Left - Rear Right - Front Center - Woofer - Side Left - Side Right
Limits: Playback 0 - 65536
Mono:
Front Left: Playback 65536 [100%] [on]
Front Right: Playback 65536 [100%] [on]
Rear Left: Playback 65536 [100%] [on]
Rear Right: Playback 65536 [100%] [on]
Front Center: Playback 65536 [100%] [on]
Woofer: Playback 65536 [100%] [on]
Side Left: Playback 65536 [100%] [on]
Side Right: Playback 65536 [100%] [on]
I also tried manually setting the motherboard NB Azalia to Enabled and the Audio IOs to a manual setting (both were auto before).
Here is my audio configuration:
# Switches to Pipewire
pulseaudio.enable = false;
udev.packages = [ pkgs.alsa-utils ];
pipewire = {
enable = true;
alsa.enable = true;
alsa.support32Bit = true;
pulse.enable = true;
#jack.enable = true;
wireplumber = {
enable = true;
extraConfig."11-bluetooth-policy" = {
"wireplumber.settings" = {
"bluetooth.autoswitch-to-headset-profile" = false;
};
};
};
extraConfig.pipewire = {
"92-low-latency" = {
# Increase quant value until no more crackles (underruns)
"context.properties" = {
"default.clock.rate" = 48000;
"default.clock.allowed-rates" = [
32000
44100
48000
];
"default.clock.quantum" = 64;
"default.clock.min-quantum" = 32;
"default.clock.max-quantum" = 64;
"default.clock.quantum-limit" = 64;
};
};
};
};
kernelModules = [
"snd_hda_intel"
"snd_pcm_oss"
];
extraModprobeConfig = ''
options snd slots=snd-hda-intel
'';
At this point I am sadly at a loss at what to do, any help would be greatly appreciated
